Build a URL Shortener: Cloudflare Workers + KV

Why Build Your Own URL Shortener

Bit.ly charges $8/month for custom domains and 500 branded links. Rebrandly charges $29/month. For an African startup where every dollar counts, paying ₦12,000/month for URL shortening is wasteful.

With Cloudflare Workers and KV, you build a URL shortener that handles millions of redirects, runs at 300+ edge locations, and costs exactly $0 on the free tier. You own the data, you own the domain, and you never hit someone else's rate limit.

The Free Stack

Total cost: $0/month

Step 1: Set Up the Project

npm install -g wrangler
wrangler login
mkdir url-shortener && cd url-shortener
wrangler init

Update wrangler.toml:

name = "url-shortener"
main = "src/index.js"
compatibility_date = "2026-01-01"

[[kv_namespaces]]
binding = "LINKS"
id = "your-kv-namespace-id"

[vars]
BASE_URL = "https://s.yourdomain.com"

Create the KV namespace:

wrangler kv:namespace create LINKS

Step 2: Build the Core Shortener

// src/index.js
function generateId(length = 6) {
  const chars = 'abcdefghijklmnopqrstuvwxyzABCDEFGHIJKLMNOPQRSTUVWXYZ0123456789'
  let result = ''
  for (let i = 0; i < length; i++) {
    result += chars.charAt(Math.floor(Math.random() * chars.length))
  }
  return result
}

function isUrlValid(string) {
  try {
    new URL(string)
    return true
  } catch {
    return false
  }
}

export default {
  async fetch(request, env, ctx) {
    const url = new URL(request.url)
    const path = url.pathname

    // POST /api/shorten — create a short link
    if (path === '/api/shorten' && request.method === 'POST') {
      const authHeader = request.headers.get('Authorization')
      if (authHeader !== 'Bearer ' + env.ADMIN_TOKEN) {
        return Response.json({ error: 'Unauthorized' }, { status: 401 })
      }

      const body = await request.json()
      const { url: longUrl, customCode } = body

      if (!longUrl || !isUrlValid(longUrl)) {
        return Response.json({ error: 'Valid URL required' }, { status: 400 })
      }

      const code = customCode || generateId()
      const existing = await env.LINKS.get(code)

      if (existing) {
        return Response.json({ error: 'Code already in use' }, { status: 409 })
      }

      const linkData = {
        originalUrl: longUrl,
        createdAt: new Date().toISOString(),
        clicks: 0,
        country: request.cf?.country || 'unknown'
      }

      await env.LINKS.put(code, JSON.stringify(linkData))
      return Response.json({
        shortUrl: env.BASE_URL + '/' + code,
        code,
        originalUrl: longUrl
      }, { status: 201 })
    }

    // GET /api/stats/:code — get link stats
    if (path.startsWith('/api/stats/') && request.method === 'GET') {
      const code = path.split('/').pop()
      const data = await env.LINKS.get(code)

      if (!data) {
        return Response.json({ error: 'Link not found' }, { status: 404 })
      }

      return Response.json({ code, ...JSON.parse(data) })
    }

    // GET /:code — redirect to original URL
    if (path.length > 1 && request.method === 'GET') {
      const code = path.slice(1)
      const data = await env.LINKS.get(code)

      if (!data) {
        return new Response('Link not found', { status: 404 })
      }

      const link = JSON.parse(data)
      link.clicks += 1
      ctx.waitUntil(env.LINKS.put(code, JSON.stringify(link)))

      return Response.redirect(link.originalUrl, 301)
    }

    // GET / — admin dashboard or landing page
    return Response.json({
      service: 'URL Shortener',
      endpoints: {
        'POST /api/shorten': 'Create a short link',
        'GET /:code': 'Redirect to original URL',
        'GET /api/stats/:code': 'Get link analytics'
      }
    })
  }
}

Step 3: Add Rate Limiting

Prevent abuse without spending a cent:

// Rate limiting using KV with expiration
async function checkRateLimit(env, ip) {
  const key = 'ratelimit:' + ip
  const current = parseInt(await env.LINKS.get(key) || '0')

  if (current >= 10) {
    return false // 10 shortens per hour
  }

  await env.LINKS.put(key, String(current + 1), { expirationTtl: 3600 })
  return true
}

// Add to your POST /api/shorten handler:
const ip = request.headers.get('cf-connecting-ip') || 'unknown'
if (!(await checkRateLimit(env, ip))) {
  return Response.json({ error: 'Rate limit exceeded' }, { status: 429 })
}

Step 4: Build a Simple Admin Frontend

Create a single-page admin that you can deploy on Cloudflare Pages:

<!-- public/index.html -->
<!DOCTYPE html>
<html>
<head>
  <title>URL Shortener Admin</title>
  <script src="https://cdn.tailwindcss.com"></script>
</head>
<body class="min-h-screen bg-gray-50 p-8">
  <div class="max-w-md mx-auto space-y-6">
    <h1 class="text-2xl font-bold">URL Shortener</h1>
    <div>
      <input id="longUrl" placeholder="https://your-long-url.com/page"
        class="w-full border rounded-lg px-4 py-2 mb-2" />
      <input id="customCode" placeholder="Custom code (optional)"
        class="w-full border rounded-lg px-4 py-2 mb-2" />
      <button onclick="shorten()" class="w-full bg-black text-white py-2 rounded-lg">
        Shorten URL
      </button>
    </div>
    <div id="result" class="hidden bg-green-50 border border-green-200 rounded-lg p-4">
      <p class="text-sm text-gray-600">Short URL:</p>
      <a id="shortUrl" class="text-blue-600 font-mono text-lg"></a>
    </div>
  </div>
  <script>
    async function shorten() {
      const url = document.getElementById('longUrl').value
      const customCode = document.getElementById('customCode').value
      const token = localStorage.getItem('admin_token') || prompt('Enter admin token:')
      localStorage.setItem('admin_token', token)

      const res = await fetch('/api/shorten', {
        method: 'POST',
        headers: {
          'Content-Type': 'application/json',
          'Authorization': 'Bearer ' + token
        },
        body: JSON.stringify({ url, customCode })
      })

      const data = await res.json()
      if (data.error) { alert(data.error); return }

      document.getElementById('shortUrl').href = data.shortUrl
      document.getElementById('shortUrl').textContent = data.shortUrl
      document.getElementById('result').classList.remove('hidden')
    }
  </script>
</body>
</html>

Step 5: Deploy and Add Custom Domain

wrangler deploy
# Your shortener is live at https://url-shortener.your-name.workers.dev

Add a short custom domain:

• Go to Cloudflare Dashboard → Workers → your worker → Triggers
• Click Add Custom Domain
• Enter s.yourdomain.com (short domains look better in texts and social media)

In Nigeria, a .com.ng domain costs ₦2,500/year. A 2-letter subdomain like s.yourdomain.com.ng is perfect for sharing on WhatsApp and Twitter.

Cost Comparison: Build vs Buy

At scale (1M+ redirects/month), your Cloudflare Workers cost is $5/month. Bit.ly would cost $8–$29. Your solution is cheaper and you own every byte of data.

Common Mistakes
